US Motors D60P2FS 60 HP 4-Pole ODP 3-Phase 1780 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Assembly Position | F1 |
| Breakdown Torque | 246 |
| Breakdown Torque Uom | PERCENT OF FLT |
| Frme | 364 |
| Full Load Amps Primary | 69 |
| Hertz | 60 |
| Hertz 2 | 50 |
| Horsepower | 60 HP |
| Insulation Class | F |
| Kilowatts | 44.7 |
| Kva Code Letter | G |
| Locked Rotor Amps | 433 |
| Locked Rotor Torque Uom | PERCENT OF FLT |
| Locked-Rotor Torque | 200 |
| Motor Enclosure | ODP |
| Motor Type | DE |
| Mounting | HORZ-FOOTED |
| Nema Nominal Efficiency | 95 |
| Number Speeds | 1 |
| Opposite End Bearing | 6212-2Z-J/C3 |
| Phasetype | 3_PHASE |
| Poles | 4 |
| Rpm 4 | 1480 |
| Service Factor | 1.15 |
| Service Factor Amps Primary | 80 |
| Shaft Code | TS |
| Shaft End Bearing | 6212-2Z-J/C3 |
| Shipping Weight | 545 |
| Speed | 1780 RPM |
| Startcapmfd | N\A |
| Volts | 460 |
| Volts 4 | 400 |
| Volts Primary | 460 |
Frequently Asked Questions
How do I get pricing for D60P2FS?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the D60P2FS?
D60P2FS is a US Motors part. KKM Solutions sources US Motors components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of D60P2FS?
Key specifications include Ambient: 40; Assembly Position: F1; Breakdown Torque: 246; Breakdown Torque Uom: PERCENT OF FLT. The full specification table on this page lists every published attribute for this part.
How quickly can D60P2FS ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
