US Motors D15P3E 15 HP 6-Pole ODP 3-Phase 1180 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Assembly Position | F1 |
| Breakdown Torque | 311 |
| Breakdown Torque Uom | PERCENT OF FLT |
| Frme | 284 |
| Full Load Amps Primary | 37/18.5 |
| Hertz | 60 |
| Hertz 2 | 50 |
| Horsepower | 15 HP |
| Insulation Class | F |
| Kilowatts | 11.2 |
| Kva Code Letter | H |
| Locked Rotor Amps | 136.4 |
| Locked Rotor Torque Uom | PERCENT OF FLT |
| Locked-Rotor Torque | 233 |
| Motor Enclosure | ODP |
| Motor Type | DE |
| Mounting | HORZ-FOOTED |
| Nema Nominal Efficiency | 91.7 |
| Number Speeds | 1 |
| Opposite End Bearing | 6309-2Z-J/C3 |
| Phasetype | 3_PHASE |
| Poles | 6 |
| Rpm 2 | 1180 |
| Rpm 4 | 980 |
| Rpm 5 | 980 |
| Service Factor | 1.15 |
| Service Factor Amps Primary | 42/21 |
| Shaft Code | T |
| Shaft End Bearing | 6310-2Z-J/C3 |
| Shipping Weight | 225 |
| Speed | 1180 RPM |
| Startcapmfd | N\A |
| Volts | 460 |
| Volts 2 | 230 |
| Volts 4 | 400 |
| Volts 5 | 200 |
| Volts Primary | 230/460 |
Frequently Asked Questions
How do I get pricing for D15P3E?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the D15P3E?
D15P3E is a US Motors part. KKM Solutions sources US Motors components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of D15P3E?
Key specifications include Ambient: 40; Assembly Position: F1; Breakdown Torque: 311; Breakdown Torque Uom: PERCENT OF FLT. The full specification table on this page lists every published attribute for this part.
How quickly can D15P3E ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
