US Motors CD2P2E 2 HP 4-Pole TEFC-IP55 3-Phase 1750 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Assembly Position | F1 |
| Breakdown Torque | 398 |
| Breakdown Torque Uom | PERCENT OF FLT |
| Frme | 145 |
| Full Load Amps Primary | 6-5.6/2.8 |
| Hertz | 60 |
| Hertz 2 | 50 |
| Horsepower | 2 HP |
| Insulation Class | F |
| Kilowatts | 1.5 |
| Kva Code Letter | K |
| Locked Rotor Amps | 23.5 |
| Locked Rotor Torque Uom | PERCENT OF FLT |
| Locked-Rotor Torque | 310 |
| Motor Enclosure | TEFC-IP55 |
| Motor Type | TCE |
| Mounting | HORZ-FOOTED |
| Nema Nominal Efficiency | 86.5 |
| Number Speeds | 1 |
| Opposite End Bearing | 6203-J/C3 |
| Phasetype | 3_PHASE |
| Poles | 4 |
| Rotation | DUAL |
| Rpm 2 | 1750 |
| Rpm 3 | 1735 |
| Rpm 4 | 1435 |
| Rpm 5 | 1435 |
| Service Factor | 1.25 |
| Service Factor Amps Primary | 0-6.7/3.4 |
| Shaft Code | T |
| Shaft End Bearing | 6205-J/C3 |
| Shipping Weight | 70 |
| Speed | 1750 RPM |
| Startcapmfd | N\A |
| Volts | 460 |
| Volts 2 | 230 |
| Volts 3 | 208 |
| Volts 4 | 400 |
| Volts 5 | 200 |
| Volts Primary | 208-230/460 |
Frequently Asked Questions
How do I get pricing for CD2P2E?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the CD2P2E?
CD2P2E is a US Motors part. KKM Solutions sources US Motors components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of CD2P2E?
Key specifications include Ambient: 40; Assembly Position: F1; Breakdown Torque: 398; Breakdown Torque Uom: PERCENT OF FLT. The full specification table on this page lists every published attribute for this part.
How quickly can CD2P2E ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
