Swagelok SS-4BK-1C — Straight Pattern, with Actuator
Swagelok SS-4BK-1C - Straight Pattern, with Actuator - Actuator type: Pneumatic; Body material: 316 Stainless Steel; Connection 1 Type: Swagelok® Tube Fitting.
In our catalog, the SS-4BK-1C from Swagelok is listed under the Straight Pattern, with Actuator category. The manufacturer's published data for this part number specifies Actuator type: Pneumatic and Body material: 316 Stainless Steel.
Key manufacturer data on file for this item includes Connection 1 Type: Swagelok® Tube Fitting; Connection 2 Type: Swagelok® Tube Fitting; Cleaning Process: Special Cleaning and Packaging (SC-11); Connection 1 Size: 1/4 in.; Connection 2 Size: 1/4 in.; Maximum Temperature, °F (°C): 200 (93); Minimum Temperature, °F (°C): -20 (-28); Testing: Helium leak testing according to SCS-00020; CV Maximum: 0.3; Max Temperature Pressure Rating: 200°F @ 125 PSIG /93°C @ 8.6 BAR; Room Temperature Pressure Rating: 125 PSIG @ 100°F /8.6 BAR @ 37°C; Stem Tip Material: PCTFE. See the Specifications tab on this page for the full technical table.
| Actuator Model | 1 Series |
|---|---|
| Actuator Operation Mode | Normally Closed Spring Return |
| Actuator type | Pneumatic |
| Bellows Material | 321 Stainless Steel |
| Body material | 316 Stainless Steel |
| Body Seal | Gasket with soft seat |
| Cleaning Process | Special Cleaning and Packaging (SC-11) |
| Connection 1 Size | 1/4 in. |
| Connection 1 Type | Swagelok® Tube Fitting |
| Connection 2 Size | 1/4 in. |
| Connection 2 Type | Swagelok® Tube Fitting |
| CV Maximum | 0.3 |
| Flow Pattern | Straight (2-way) |
| Gasket | PTFE-Coated 316 SS Gasket |
| Max Temperature Pressure Rating | 200°F @ 125 PSIG /93°C @ 8.6 BAR |
| Maximum Temperature, °F (°C) | 200 (93) |
| Minimum Temperature, °F (°C) | -20 (-28) |
| Room Temperature Pressure Rating | 125 PSIG @ 100°F /8.6 BAR @ 37°C |
| Service Class | General |
| Stem Tip Material | PCTFE |
| Stem Type | Conical |
| Surface Finish | Standard |
| Testing | Helium leak testing according to SCS-00020 |
Frequently Asked Questions
How do I get pricing for SS-4BK-1C?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the SS-4BK-1C?
SS-4BK-1C is a Swagelok part. KKM Solutions sources Swagelok components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of SS-4BK-1C?
Key specifications include Actuator Model: 1 Series; Actuator Operation Mode: Normally Closed Spring Return; Actuator type: Pneumatic; Bellows Material: 321 Stainless Steel. The full specification table on this page lists every published attribute for this part.
How quickly can SS-4BK-1C ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Related Products
Swagelok Swagelok Stainless Steel Bellows Sealed Valve, Gasketed, PCTFE Stem…
Swagelok Swagelok Brass Toggle Valve, 1/8 in. FNPT, NC Actuator
