Omron NX-ID4342 Fieldbus, decentr. periphery - digital I/O module
Omron NX-ID4342 is an 8-point DC NPN digital input module with 24 VDC, DIN rail mounting, and screwless terminals.
The Omron NX-ID4342 is a digital I/O module designed for decentralized fieldbus applications, featuring 8 DC NPN input points with 24 VDC operation. It mounts on DIN rail and uses a screwless, removable terminal block for quick wiring.
Each input has a current draw of 3.5 mA, with an input on time of 20 µs and an off time of 400 µs. The module requires an NX-PF power supply and complies with cULus (Class I Division 2), NK, Lloyds, EC Directives, and KC Registration standards. Its compact width is 12mm.
| Input current | 3.5 mA |
|---|---|
| Input Off Time | 400 µs |
| Input On Time | 20 µs |
| Input type | DC NPN |
| Input Voltage | 24 VDC |
| Manual | W521 |
| Module width | 12mm |
| Mounting | DIN Rail |
| Number of Input Points | 8 |
| Number of Inputs Per Common | 1 |
| NX-PF Power Supply Required | Yes |
| Standards | cULus (Class I Division 2 Products for Hazardous Locations), NK, Lloyds, EC Directives, and KC Registration |
| Terminal Type | Screwless Clamping Terminal Block, removable |
| Type | Digital-IO |
