Omron NX-ID3417 Fieldbus, decentr. periphery - digital I/O module
Omron NX-ID3417 is a 4-point DC PNP digital input module for DIN rail mounting with screwless terminals and 12-24 VDC operation.
The Omron NX-ID3417 is a digital I/O module designed for decentralized fieldbus applications, featuring four DC PNP input points. It mounts on DIN rail and uses a removable screwless clamping terminal block for easy wiring.
Each input operates at 12-24 VDC with a 6 mA input current, and inputs are individually isolated with one input per common. The module has an input on time of 20 µs and an input off time of 400 µs. It requires an NX-PF power supply and complies with cULus (Class I Division 2), NK, Lloyds, EC Directives, and KC Registration standards. The module width is 12mm.
| Input current | 6 mA |
|---|---|
| Input Off Time | 400 µs |
| Input On Time | 20 µs |
| Input type | DC PNP |
| Input Voltage | 12-24 VDC |
| Manual | W521 |
| Module width | 12mm |
| Mounting | DIN Rail |
| Number of Input Points | 4 |
| Number of Inputs Per Common | 1 |
| NX-PF Power Supply Required | Yes |
| Standards | cULus (Class I Division 2 Products for Hazardous Locations), NK, Lloyds, EC Directives, and KC Registration |
| Terminal Type | Screwless Clamping Terminal Block, removable |
| Type | Digital-IO |
Frequently Asked Questions
How do I get pricing for NX-ID3417?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the NX-ID3417?
NX-ID3417 is a Omron part. KKM Solutions sources Omron components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of NX-ID3417?
Key specifications include Input current: 6 mA; Input Off Time: 400 µs; Input On Time: 20 µs; Input type: DC PNP. The full specification table on this page lists every published attribute for this part.
How quickly can NX-ID3417 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
