Evaluation system and display for analog signals - DP2200
IFM DP2200 - Evaluation system and display for analog signals - Material: housing: PA; Weight: 84.4; Storage Temperature: -25...70.
This listing covers the IFM DP2200, a part number in the Evaluation system and display for analog signals category. The manufacturer's published data for this part number specifies Material: housing: PA and Weight: 84.4.
For the reliable limit value monitoring of analog sensors; Clearly visible LED display with red/green color change; Compact housing with high protection rating; Easy parameter setting via rotary switch
The specification set recorded for this part number covers Storage Temperature: -25...70; Ambient temperature: -25...60; Connector: 1 x M12; coding: A; Contacts: 4; Dimensions: 63 x 30 x 24; Number of digital outputs: 1; Application: decentralized display, preprocessing and conversion of analog signals; Pollution degree: 2; Product type: Evaluation system and display for analog signals; Accuracy: 0.75; (% of the final value of the measuring range analog input); Communication interface: IO-Link; Operating voltage: 18...30 DC; (to SELV/PELV); Current consumption: 30...900. The complete technical table is shown in the Specifications tab on this page.
| Accuracy | 0.75; (% of the final value of the measuring range analog input) |
|---|---|
| Ambient temperature | -25...60 |
| Analog current output | 4...20 |
| Analog input (current) | 4...20 |
| Application | decentralized display, preprocessing and conversion of analog signals |
| Communication interface | IO-Link |
| Connector | 1 x M12; coding: A; Contacts: 4 |
| Current consumption | 30...900 |
| Dimensions | 63 x 30 x 24 |
| Housing | rectangular |
| IO-Link revision | 1.1 |
| Key Features | For the reliable limit value monitoring of analog sensors; Clearly visible LED display with red/green color change; Compact housing with high protection rating; Easy parameter setting via rotary switch |
| Material | housing: PA |
| Max. current load per output | 50 |
| Max. current load total | 0.8 |
| Max. height above sea level | 4000 |
| Max. relative air humidity | 90; (linearly decreasing to 50 % (40 °C); non condensing) |
| Min. process cycle time | 3.2 |
| MTTF | 373 |
| Nominal voltage DC | 24 |
| Number of Analog Inputs | 1 |
| Number of analog outputs | 1 |
| Number of digital outputs | 1 |
| Number of inputs and outputs | Number of analog inputs: 1; Number of digital outputs: 1; Number of analog outputs: 1 |
| Operating voltage | 18...30 DC; (to SELV/PELV) |
| Output function | normally open / closed; (configurable) |
| Pack quantity | 1 pcs. |
| Pollution degree | 2 |
| Process data analog | 1 |
| Process data binary | 1 |
| Product type | Evaluation system and display for analog signals |
| Protection | IP 67 |
| Required master port class | A |
| Resolution of analog input | 10 Bit |
| SDCI standard | IEC 61131-9 |
| Sensor supply of the inputs | from the operating voltage |
| SIO mode | yes |
| Specification Summary | Measured value and limit value display / converter 4…20 mA – IO-Link; 63 x 30 x 24 mm; IP 67; Connector |
| Storage Temperature | -25...70 |
| Transmission type | COM2 (38,4 kBaud) |
| Voltage range DC | 10...30 |
| Weight | 84.4 |
Frequently Asked Questions
How do I get pricing for DP2200?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the DP2200?
DP2200 is a IFM part. KKM Solutions sources IFM components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of DP2200?
Key specifications include Accuracy: 0.75; (% of the final value of the measuring range analog input); Ambient temperature: -25...60; Analog current output: 4...20; Analog input (current): 4...20. The full specification table on this page lists every published attribute for this part.
How quickly can DP2200 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Related Products
IFM Evaluation system and display for analog signals - DP4200
IFM Evaluation system and display for analog signals - UA0041
IFM Evaluation system and display for analog signals - UA0044
IFM Evaluation system and display for analog signals - UA0043
