Garlock BLUE-GARD® Style 3200 Pipe Flange Gaskets
BLUE-GARD® Style 3200 Ring Gasket, Aramid Fiber with SBR Binder, 1 1/2 Inch ASME B16.5 Class 300, 0.063 Inch Thick
| Brand | BLUE-GARD® |
|---|---|
| Color | Off-White |
| Compliances | REACH Compliant, RoHS Compliant |
| Compliances/Standards | REACH Compliant, RoHS Compliant |
| Composition | Aramid Fiber with SBR Binder |
| Fiber | Aramid |
| Gasket Type | Ring |
| Inside Diameter (Inch) | 1.906 |
| Inside Diameter (mm) | 48.41 |
| Max Temperature (C) | 371 |
| Max Temperature (F) | 700 |
| Min Temperature (C) | -73 |
| Min Temperature (F) | -100 |
| Nominal Pipe Size (inch) | 1.500 |
| Nominal Pipe Size Fraction (Inch) | 1 1/2 |
| Outside Diameter (inch) | 3.750 |
| Outside Diameter (mm) | 95.25 |
| Pressure Class | 300 |
| Pressure Max (bar) | 83 |
| Pressure Max (psi) | 1200 |
| Primary Dimensional Unit of Measure | Imperial |
| Primary Nominal Thickness | 1/16 |
| Rubber Chemical Name | Styrene-butadiene |
| Rubber Material | SBR |
| Rubber Material Abbreviation | SBR |
| Shipping Weight | 0.029 lbs |
| Sort Priority | 410 |
| Style/Model | Style 3200 |
| Temperature Range (C) | -73°C - 371°C |
| Temperature Range (F) | -100°F - 700°F |
| Thickness (inch) | 0.063 |
| Thickness (mm) | 1.60 |
Frequently Asked Questions
How do I get pricing for 37702-0293?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 37702-0293?
37702-0293 is a Garlock part. KKM Solutions sources Garlock components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 37702-0293?
Key specifications include Brand: BLUE-GARD®; Color: Off-White; Compliances: REACH Compliant, RoHS Compliant; Compliances/Standards: REACH Compliant, RoHS Compliant. The full specification table on this page lists every published attribute for this part.
How quickly can 37702-0293 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
