Garlock BLUE-GARD® Style 3700 Pipe Flange Gaskets
BLUE-GARD® Style 3700 Ring Gasket, Aramid Fiber with EPDM Binder, 44 Inch ASME B16.47 Series A Class 150, 0.125 Inch Thick
| Brand | BLUE-GARD® |
|---|---|
| Color | Light Gray |
| Compliances | REACH Compliant, RoHS Compliant |
| Compliances/Standards | REACH Compliant, RoHS Compliant |
| Composition | Aramid Fiber with EPDM Binder |
| Fiber | Aramid |
| Flange Standards/Pressure Class | ASME B16.47 Series A Class 150 |
| Gasket Type | Ring |
| Inside Diameter (Inch) | 44.000, 44 |
| Inside Diameter (mm) | 1117.60 |
| Max Temperature (C) | 371 |
| Max Temperature (F) | 700 |
| Min Temperature (C) | -73 |
| Min Temperature (F) | -100 |
| Nominal Pipe Size (inch) | 44.000 |
| Nominal Pipe Size DN (mm) | 1118.0 |
| Nominal Pipe Size Fraction (Inch) | 44 |
| Outside Diameter (inch) | 50.250 |
| Outside Diameter (mm) | 1276.35 |
| Pipe Standard and Class | ASME B16.47 Series A Class 150 |
| Pressure Class | 150 |
| Pressure Max (bar) | 83 |
| Pressure Max (psi) | 1200 |
| Primary Dimensional Unit of Measure | Imperial |
| Primary Nominal Thickness | 1/8 |
| Rubber Chemical Name | Ethylene Propylene Diene Monomer |
| Rubber Material | EPDM |
| Shipping Weight | 3.112 lbs |
| Sort Priority | 450 |
| Style/Model | Style 3700 |
| Temperature Range (C) | -73°C - 371°C |
| Temperature Range (F) | -100°F - 700°F |
| Thickness (inch) | 0.125 |
| Thickness (mm) | 3.18 |
Frequently Asked Questions
How do I get pricing for 37705-1144?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 37705-1144?
37705-1144 is a Garlock part. KKM Solutions sources Garlock components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 37705-1144?
Key specifications include Brand: BLUE-GARD®; Color: Light Gray; Compliances: REACH Compliant, RoHS Compliant; Compliances/Standards: REACH Compliant, RoHS Compliant. The full specification table on this page lists every published attribute for this part.
How quickly can 37705-1144 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
