Endress+Hauser Micropilot S FMR540
| Accuracy | +/- 1 mm |
|---|---|
| Ambient temperature | Standard: -40°C...80°C (-40°F...176°F) For calibration to regulatory standards: -25°C...60°C (-13°F...131°F) |
| Application limits | Maximum measuring range is dependent on the tank form and/or application Strong condensate or build-up formation FMR53x Existing stilling wells with non-ideal measuring conditions FMR532 |
| Certificates / Approvals | ATEX, FM, CSA, IEC Ex, NEPSI |
| Characteristic / Application | Horn antenna: High precision measurement for for storage tanks up to 20 m (65ft) Parabolic antenna: High precision measurement for free space applications up to 40 m (131 ft) |
| Communication | 4...20 mA HART |
| Frequency | K-band (~26 GHz) |
| Main wetted parts | 316L |
| Measuring principle | Level radar |
| Process Connection | Horn Antenna: DN100, DN150 Flange UNIFlange DN150, DN200, DN250 Parabolic antenna: UNIflange with Top Target positioner DN200, DN250 For dk value < 1.9, contact Endress+Hauser |
| Process pressure / max. overpressure limit | Horn: Vacuum...16 bar (232 psi) Parabolic: Vacuum...6 bar (87 psi) Use of UNIflange: Vacuum...1 bar (14.5 psi) |
| Process temperature | -40°C...200°C (-40°F...392°F) |
| Supply / Communication | 4-wire (HART) |
Frequently Asked Questions
How do I get pricing for FMR540?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the FMR540?
FMR540 is a Endress+Hauser part. KKM Solutions sources Endress+Hauser components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of FMR540?
Key specifications include Accuracy: +/- 1 mm; Ambient temperature: Standard: -40°C...80°C (-40°F...176°F) For calibration to regulatory standards: -25°C...60°C (-13°F...131°F); Application limits: Maximum measuring range is dependent on the tank form and/or application Strong condensate or build-up formation FMR53x Existing stilling wells with non-ideal measuring conditions FMR532; Certificates / Approvals: ATEX, FM, CSA, IEC Ex, NEPSI. The full specification table on this page lists every published attribute for this part.
How quickly can FMR540 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
