Bosch Rexroth LINEAR SLIDE SGK-180-NN-1
Closed format for unsupported installation. High feed forces. Particularly suitable for environments with high contamination levels (closed bellows). High travel speed due to large leads. Rexroth precision ball screw assembly in rolled version, tolerance grade T7 in accordance with DIN 69051 with backlash-free cylindrical nut. Cost-effective maintenance through central lubrication (grease lubrication) on both sides of the guide system
| Dynamic load capacity, ball screw assembly Cbs [N] | 15700 |
|---|---|
| Dynamic load capacity, fixed bearing Cfb [N] | 17000 |
| Dynamic load capacity, guideway Cgw [N] | 15600 |
| Dynamic longitudinal moment load capacity ML [Nm] | 787.0 |
| Dynamic torsional moment load capacity Mt [Nm] | 748.0 |
| Linear axes variant | Closed with ball screw assembly |
| Max. length Lmax [mm] | 3000.0 |
| Maximum acceleration rate amax [m/s²] | 27.0 |
| Maximum dynamic load in y-direction Fy max [N] | 5580 |
| Maximum dynamic load in z-direction Fz max [N] | 5580 |
| Maximum permissible dynamic torsional moment about the x-axis Mx max [Nm] | 268 |
| Maximum permissible dynamic torsional moment about the y-axis My max [Nm] | 282 |
| Maximum permissible dynamic torsional moment about the z-axis Mz max [Nm] | 282 |
| Maximum permissible linear speed vmax [m/s] | 1.26 |
| Nominal size [mm] | SGK-180 |
| Note: Permissible ambient temperature with Rexroth servo motor (min. ... max.) | No dropping below dew point |
| Permissible ambient temperature with Rexroth servo motor (min. ... max.) | 0 °C ... 40 °C |
| Weight (Kg) | 0.000000 |
Frequently Asked Questions
How do I get pricing for R026140000?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the R026140000?
R026140000 is a Bosch Rexroth part. KKM Solutions sources Bosch Rexroth components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of R026140000?
Key specifications include Dynamic load capacity, ball screw assembly Cbs [N]: 15700; Dynamic load capacity, fixed bearing Cfb [N]: 17000; Dynamic load capacity, guideway Cgw [N]: 15600; Dynamic longitudinal moment load capacity ML [Nm]: 787.0. The full specification table on this page lists every published attribute for this part.
How quickly can R026140000 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
