Allen-Bradley Compact Comb Starter W/Ckt-Bkr 190S-ANEJ1-JB10C
Allen-Bradley 190S-ANEJ1-JB10C - industrial components - Width: 45 mm mm; Height: 215 mm mm; Lifecycle Status: Discontinued.
This listing covers the Allen-Bradley 190S-ANEJ1-JB10C, a part number in the industrial components category. The manufacturer's published data for this part number specifies Width: 45 mm mm and Height: 215 mm mm.
Key manufacturer data on file for this item includes Lifecycle Status: Discontinued; Build America, Buy America: No; Repair Options Available: No; Depth: 181 mm; Overload release current setting: 0.63 A; Type of electrical connection for auxiliary- and control current circuit: Screw connection; Type of electrical connection of main circuit: Screw connection; Type of motor starter: Direct online starter (DOL); Voltage type for actuating: DC; With short-circuit release: true; Circuit breaker auxiliary and trip contacts for 140M: Internal 140M auxiliary contact 1 NO + 1 NC; Circuit breaker frame size: 140M-C2T, high break. The complete technical table is shown in the Specifications tab on this page.
| Build America, Buy America | No |
|---|---|
| Circuit breaker auxiliary and trip contacts for 140M | Internal 140M auxiliary contact 1 NO + 1 NC |
| Circuit breaker frame size | 140M-C2T, high break |
| Coil voltage | 24V DC with electronic coil |
| Contactor size | 100-C09 |
| Depth | 181 mm |
| Fuse or circuit breaker per NEC, max | 450 A @ C-Frame with Bulletin 100-C/104-C Contactors |
| Height | 215 mm mm |
| Hp ratings as a UL508/CSA motor controller in group motor installations | 3/4Hp @ 575V AC, 60 Hz (with C-frame, 100-C/104-C contactors) |
| Hp ratings as a UL508/CSA self-protected Type E combination motor controller | 3/4Hp @ 575V AC, 60 Hz (with C-frame, 100-C/104-C contactors and spacing adapter) |
| Hp ratings as a UL508/CSA Type F combination motor controller | 3/4Hp @ 575V AC, 60 Hz (with C-frame, 100-C/104-C contactors and spacing adapter) |
| kW ratings as a IEC for standard motor, 1500 rpm, max | 0.55 kW @ 690V AC @ 50Hz (with C-frame, 100-C/104-C contactors) |
| Lifecycle Status | Discontinued |
| Modifications, accessories | 140M auxiliary contact, side mount, 2 NC |
| Number of auxiliary contacts as normally closed contact | 1 |
| Overload release current setting | 0.63 A |
| Rated control supply voltage at DC | 24 V |
| Repair Options Available | No |
| Short-circuit current as a IEC (Type 1 coordination), max | 65kA @ 500V AC, (with C-frame, 100-C/104-C contactors) |
| Short-circuit current as a IEC (Type 2 coordination), max | 65kA @ 500V AC, (with C-frame, 100-C/104-C contactors) |
| Short-circuit current as a UL508/CSA motor controller in group motor installations (Type 1 coordination), max | 65kA @ 480V AC, C-frame with 100-C/104-C contactors |
| Short-circuit current as a UL508/CSA motor controller in group motor installations (Type 2 coordination), max | 65kA @ 480V AC, C-frame with 100-C/104-C contactors |
| Short-circuit current as a UL508/CSA self-protected Type E combination motor controller, max | 65 kA @ 480Y/277V AC, (with C-frame, 100-C/104-C contactors and spacing adapter) |
| Short-circuit current as a UL508/CSA Type F combination motor controller (Type 1 coordination), max | 65 kA @ 480Y/277V AC, (with C-frame, 100-C/104-C contactors and spacing adapter) |
| Short-circuit current as a UL508/CSA Type F combination motor controller (Type 2 coordination), max | 65 kA @ 480Y/277V AC, (with C-frame, 100-C/104-C contactors and spacing adapter) |
| Style | Open type |
| Type of electrical connection for auxiliary- and control current circuit | Screw connection |
| Type of electrical connection of main circuit | Screw connection |
| Type of motor starter | Direct online starter (DOL) |
| Voltage type for actuating | DC |
| Width | 45 mm mm |
| With short-circuit release | true |
