US Motors GM25 40 HP 6-Pole TEAO 3-Phase 1190 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Assembly Position | W6 |
| Breakdown Torque | 228 |
| Breakdown Torque Uom | PERCENT OF FLT |
| Frme | 364 |
| Full Load Amps Primary | 94/47 |
| Hertz | 60 |
| Horsepower | 40 HP HP |
| Insulation Class | F |
| Kilowatts | 29.8 |
| Kva Code Letter | F |
| Locked Rotor Amps | 300.3 |
| Locked Rotor Torque Uom | PERCENT OF FLT |
| Locked-Rotor Torque | 153 |
| Motor Enclosure | TEAO |
| Motor Type | TCNI |
| Mounting | HORZ-FOOTED |
| Nema Nominal Efficiency | 94.1 |
| Number Speeds | 1 |
| Opposite End Bearing | 6213-2RS-J/C3 |
| Phasetype | 3 |
| Poles | 6 |
| Rotation | DUAL |
| Rpm 2 | 1190 |
| Service Factor | 1.15 |
| Service Factor Amps Primary | 108/54 |
| Shaft Code | T |
| Shaft End Bearing | 6313-2RS-J/C3 |
| Shipping Weight | 740 |
| Speed | 1190 RPM RPM |
| Startcapmfd | N\A |
| Volts | 460 |
| Volts 2 | 230 |
| Volts Primary | 230/460 V |
Frequently Asked Questions
How do I get pricing for GM25?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the GM25?
GM25 is a US Motors part. KKM Solutions sources US Motors components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of GM25?
Key specifications include Ambient: 40; Assembly Position: W6; Breakdown Torque: 228; Breakdown Torque Uom: PERCENT OF FLT. The full specification table on this page lists every published attribute for this part.
How quickly can GM25 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
