US Motors D12P2GH .5 HP 4-Pole ODP 3-Phase 1725 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Breakdown Torque | 109.6 |
| Breakdown Torque Uom | OZFT |
| Frme | 56 |
| Full Load Amps Primary | .68 |
| Hertz | 60 |
| Horsepower | .5 HP |
| Insulation Class | B |
| Kilowatts | 0.4 |
| Kva Code Letter | M |
| Locked Rotor Amps | 4.55 |
| Locked Rotor Torque Uom | OZFT |
| Locked-Rotor Torque | 81.81 |
| Motor Enclosure | ODP |
| Motor Type | FHP |
| Mounting | RIGID |
| Nema Nominal Efficiency | 78.2 |
| Number Speeds | 1 |
| Opposite End Bearing | 6203 |
| Phasetype | 3_POLYPHASE |
| Poles | 4 |
| Rotation | REVERSIBLE |
| Service Factor | 1.25 |
| Service Factor Amps Primary | .76 |
| Shaft Code | H |
| Shaft End Bearing | 6203 |
| Shipping Weight | 24 |
| Speed | 1725 RPM |
| Stack | 1.375 |
| Stator Diameter | 6.3 |
| Thermal protection | NONE |
| Volts | 575 |
| Volts Primary | 575 V |
Frequently Asked Questions
How do I get pricing for D12P2GH?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the D12P2GH?
D12P2GH is a US Motors part. KKM Solutions sources US Motors components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of D12P2GH?
Key specifications include Ambient: 40; Breakdown Torque: 109.6; Breakdown Torque Uom: OZFT; Frme: 56. The full specification table on this page lists every published attribute for this part.
How quickly can D12P2GH ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
