Turck B2N360-Q42-E2LIUPN8X2-H1181/S97
Rectangular, plastic, PA12-GF30 | Status display via LEDs | Parameterizable filter functions for different applications | Parameterizable via teach pin | Acceleration function ± 2 g, measuring range adjustable | For vehicle electrical systems, 12 V and 24 V | Increased interference immunity 30V/m following the e1 type approval | Immune to conducted interference acc. to DIN ISO 7637-2 (SAE J 113-11) | Extended temperature range | High protection class IP68/IP69K | 7 … 30 VDC supply voltage when using the analog outputs | 10 … 30 VDC supply voltage when using the switching outputs | Programmable current and voltage output functions | All functions programmable via IO-Link / PACTware | NC or NO switch functions, available as NPN or PNP version | Process value for x and y-axis in the 16-bit IO-Link telegram | M12 x 1 male, 8-pin | Adapter cable RKC8.301T-1,5-RSC4T/TX320 required for IO-Link communication
| Ambient temperature | -40…+85 °C |
|---|---|
| Communication Protocol | IO-Link |
| Construction size | 67.7 x 42.5 x 42.5 mm |
| Country of origin | DE |
| Current output | 0…20 mA |
| EAN | 4047101281989 |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Plastic, PA12-GF30 |
| Measuring principle | Acceleration |
| Measuring range | 0…360° |
| Number of measuring axes | 2 |
| Operating voltage | 7…30 VDC |
| Output function | NO/NC, PNP/NPN, analog output |
| Protection class | IP68/IP69K |
| Voltage output | 0…10 V |
| Weight | 131 g |
Frequently Asked Questions
How do I get pricing for 1534117?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 1534117?
1534117 is a Turck part. KKM Solutions sources Turck components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 1534117?
Key specifications include Ambient temperature: -40…+85 °C; Communication Protocol: IO-Link; Construction size: 67.7 x 42.5 x 42.5 mm; Country of origin: DE. The full specification table on this page lists every published attribute for this part.
How quickly can 1534117 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
