SMC ZFD Inline Air Filter, Bidirectional Flow type ZFD53
SMC ZFD53 - ZF Series Air Suction Filter category.
In our catalog, the ZFD53 from SMC is listed under the ZF Series Air Suction Filter category.
The SMC ZFD Series is an In-line Air Filter (Bidirectional Flow Type). It is designed to collect foreign matter in both the vacuum suction and vacuum break directions. This capability is crucial to prevent contaminants from being released onto the workpiece during vacuum release. ZFD series integrates filters, check valves and fittings into a single unit to save space. It also allows for easy element replacement.
Specification data for this part number is available on request from our order desk.
| Description | The SMC ZFD Series is an In-line Air Filter (Bidirectional Flow Type). It is designed to collect foreign matter in both the vacuum suction and vacuum break directions. This capability is crucial to prevent contaminants from being released onto the workpiece during vacuum release. ZFD series integrates filters, check valves and fittings into a single unit to save space. It also allows for easy element replacement. |
|---|---|
| Key Features | Collection of foreign matter in both vacuum suction and vacuum release directions; Element can be replaced with tube attached.; Filtration: 5 μm (optional: 10 μm); Operating Pressure Range: -100kPa to 0.5 MPa; Applicable Tube O.D.: ø4, ø6, and ø8 mm; Maximum Vacuum Flow: up to 140 L/min (ø8 mm) |
Frequently Asked Questions
How do I get pricing for ZFD53?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the ZFD53?
ZFD53 is a SMC part. KKM Solutions sources SMC components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of ZFD53?
Key specifications include Description: The SMC ZFD Series is an In-line Air Filter (Bidirectional Flow Type). It is designed to collect foreign matter in both the vacuum suction and vacuum break directions. This capability is crucial to prevent contaminants from being released onto the workpiece during vacuum release. ZFD series integrates filters, check valves and fittings into a single unit to save space. It also allows for easy element replacement.; Key Features: Collection of foreign matter in both vacuum suction and vacuum release directions; Element can be replaced with tube attached.; Filtration: 5 μm (optional: 10 μm); Operating Pressure Range: -100kPa to 0.5 MPa; Applicable Tube O.D.: ø4, ø6, and ø8 mm; Maximum Vacuum Flow: up to 140 L/min (ø8 mm). The full specification table on this page lists every published attribute for this part.
How quickly can ZFD53 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
