SICK PLOC2D-8305-8 (PLOC2D)
| Application | Part localization, Identification, Belt picking, Mixed-item picking, Classification |
|---|---|
| Calibration | No |
| Certificate | EU declaration of conformity, UK declaration of conformity, ACMA declaration of conformity, China RoHS, cULus certificate, Profinet certificate, Ethernet/IP certificate, Information according to Art. 3 of Data Act (Regulation EU 2023/2854) |
| Description | High resolution 2D localization of parts in medium/large fields of view at medium/long reading distances |
| Design methodology | configurable, pre-calibrated, customized, Can be programmed via plug-in |
| Dimensions (L x W x H) | 63 mm x 85 mm x 108 mm |
| Enclosure rating | IP65 |
| Focal length | 8 mm |
| Industry | Robotics, Vehicle manufacturing, Machines, powertrain and chassis, food, beverage and consumer care, Electronics |
| Light source | Visible, LED, white, 6,500 K, ± 1,000 K |
| Localization accuracy | ± 0.5 px, ± 0.1° |
| Max. working distance | 2500 |
| Measured values | Positioning |
| Min. working distance | 200 |
| New products | No |
| Object movement | dynamic, static |
| Optical focus | adjustable focus (manually) |
| Product segment | Robot guidance systems, machine vision |
| Product subsegment | 2D machine vision |
| Sensor resolution | 5.1 MP |
| Task | Localizing, navigating and guiding - Guiding |
| Technology | 2D grayscales |
| Topic of focus | Robot Vision |
| Vision system | Yes |
| Weight | 545 g |
Frequently Asked Questions
How do I get pricing for PLOC2D-8305-8?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the PLOC2D-8305-8?
PLOC2D-8305-8 is a SICK part. KKM Solutions sources SICK components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of PLOC2D-8305-8?
Key specifications include Application: Part localization, Identification, Belt picking, Mixed-item picking, Classification; Calibration: No; Certificate: EU declaration of conformity, UK declaration of conformity, ACMA declaration of conformity, China RoHS, cULus certificate, Profinet certificate, Ethernet/IP certificate, Information according to Art. 3 of Data Act (Regulation EU 2023/2854); Description: High resolution 2D localization of parts in medium/large fields of view at medium/long reading distances. The full specification table on this page lists every published attribute for this part.
How quickly can PLOC2D-8305-8 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
