SuperArc® L-56® - 0.040 in (1.0 mm), 1000 lb Accu-Trak® Drum
Lincoln Electric ED031032 - Buy America - Package: 1000 lb Accu-Trak® Drum; Diameter: 0.040 in (1.0 mm); Process: MIG (GMAW).
The Lincoln Electric ED031032 is part of the Buy America range in our industrial catalog. The manufacturer's published data for this part number specifies Package: 1000 lb Accu-Trak® Drum and Diameter: 0.040 in (1.0 mm).
High levels of manganese and silicon deoxidizers tolerate medium to heavy mill scale surfaces; Excellent toe-wetting provides optimal bead appearance; Copper coating provides superior arc-starting characteristics for long contact tip life; Supports short-circuiting, globular, axial spray and pulsed spray transfer; MicroGuard® Ultra provides superior feeding and arc stability
Published specifications for this part include Process: MIG (GMAW); AWS Classification: AWS ER70S-6 & EH11K; Welding Positions: All. The complete technical table is shown in the Specifications tab on this page.
| AWS Classification | AWS ER70S-6 & EH11K |
|---|---|
| Diameter | 0.040 in (1.0 mm) |
| Features | High levels of manganese and silicon deoxidizers tolerate medium to heavy mill scale surfaces; Excellent toe-wetting provides optimal bead appearance; Copper coating provides superior arc-starting characteristics for long contact tip life; Supports short-circuiting, globular, axial spray and pulsed spray transfer; MicroGuard® Ultra provides superior feeding and arc stability |
| Package | 1000 lb Accu-Trak® Drum |
| Process | MIG (GMAW) |
| Shielding Gas | 100% CO2, 75-95% Argon/ Balance CO2, 95-98% Argon/ Balance O2, Flow Rate: 30-50 CFH |
| Typical Applications | Medium to heavy mill scale base material; Sheet metal to 380-485 MPa (55- 70 ksi) yield strength material; Automotive repair; Robotic or hard automation; Structural steel, Pressure vessels |
| Welding Positions | All |
Frequently Asked Questions
How do I get pricing for ED031032?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the ED031032?
ED031032 is a Lincoln Electric part. KKM Solutions sources Lincoln Electric components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of ED031032?
Key specifications include AWS Classification: AWS ER70S-6 & EH11K; Diameter: 0.040 in (1.0 mm); Features: High levels of manganese and silicon deoxidizers tolerate medium to heavy mill scale surfaces; Excellent toe-wetting provides optimal bead appearance; Copper coating provides superior arc-starting characteristics for long contact tip life; Supports short-circuiting, globular, axial spray and pulsed spray transfer; MicroGuard® Ultra provides superior feeding and arc stability; Package: 1000 lb Accu-Trak® Drum. The full specification table on this page lists every published attribute for this part.
How quickly can ED031032 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
