IPTCI SUCSOFL208-24 — Flange Bearing Units
IPTCI SUCSOFL208-24 - Flange Bearing Units - Series: SUCSOFL Stainless Steel Set Screw Locking 2-Bolt Stand-Off Flange; Housing material: Stainless Steel; Overall Width: 64 mm.
IPTCI SUCSOFL208-24 is a Flange Bearing Units catalog item from IPTCI. The manufacturer's published data for this part number specifies Series: SUCSOFL Stainless Steel Set Screw Locking 2-Bolt Stand-Off Flange and Housing material: Stainless Steel.
The specification set recorded for this part number covers Overall Width: 64 mm; Dynamic Load Rating: 5660; Static Load Rating: 3300; Operating temperature - max: 250 °; Bore Diameter: 1.50 in; Industry Standard: AFBMA; Bearing Material: Stainless Steel; Closure Type: Dual Seals (B-Type); Grease Type: H1 Food Grade Grease; Mounting Type: Two (2) Bolt, Two (2) Bolt Flange; Locking Type: Set Screw; Length Through Bore: 1.937 in. The complete technical table is shown in the Specifications tab on this page.
| Bearing Material | Stainless Steel |
|---|---|
| Bore Diameter | 1.50 in |
| Closure Type | Dual Seals (B-Type) |
| Duty Type | Standard |
| Dynamic Load Rating | 5660 |
| Grease Type | H1 Food Grade Grease |
| Housing material | Stainless Steel |
| Industry Standard | AFBMA |
| Length Through Bore | 1.937 in |
| Locking Type | Set Screw |
| Mounting Type | Two (2) Bolt, Two (2) Bolt Flange |
| Operating temperature - max | 250 ° |
| Overall Width | 64 mm |
| Relubricatable | Relubricatable |
| Series | SUCSOFL Stainless Steel Set Screw Locking 2-Bolt Stand-Off Flange |
| Static Load Rating | 3300 |
