Garlock Style 98206 Pipe Flange Gaskets
Style 98206 Ring Gasket, EPDM, 10 Inch ASME B16.5 Class 150, 0.125 Inch Thick Certified to NSF/ANSI/CAN 61-G & 372
| Color | Black |
|---|---|
| Compliances | NSF® 61 Certified, REACH Compliant, RoHS Compliant |
| Compliances/Standards | NSF® 61 Certified, REACH Compliant, RoHS Compliant |
| Composition | EPDM |
| Gasket Type | Ring |
| Inside Diameter (Inch) | 10.750 |
| Inside Diameter (mm) | 273.05 |
| Max Temperature (C) | 135 |
| Max Temperature (F) | 275 |
| Nominal Pipe Size (inch) | 10.000 |
| Nominal Pipe Size Fraction (Inch) | 10 |
| Outside Diameter (inch) | 13.375 |
| Outside Diameter (mm) | 339.73 |
| Pressure Class | 150 |
| Pressure Max (bar) | 17 |
| Pressure Max (psi) | 250 |
| Primary Dimensional Unit of Measure | Imperial |
| Primary Nominal Thickness | 1/8 |
| Rubber Chemical Name | Ethylene Propylene Diene Monomer |
| Rubber Material | EPDM |
| Rubber Material Abbreviation | EPDM |
| Sort Priority | 280 |
| Style/Model | Style 98206 |
| Temperature Range (C) | -40°C - 135°C |
| Temperature Range (F) | -40°F - 275°F |
| Thickness (inch) | 0.125 |
| Thickness (mm) | 3.18 |
Frequently Asked Questions
How do I get pricing for 37982-1110?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 37982-1110?
37982-1110 is a Garlock part. KKM Solutions sources Garlock components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 37982-1110?
Key specifications include Color: Black; Compliances: NSF® 61 Certified, REACH Compliant, RoHS Compliant; Compliances/Standards: NSF® 61 Certified, REACH Compliant, RoHS Compliant; Composition: EPDM. The full specification table on this page lists every published attribute for this part.
How quickly can 37982-1110 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
