Garlock GYLON® Style 3510 Pipe Flange Gaskets
GYLON® Style 3510 Full Face Gasket, PTFE with Barium Sulfate EN 1514-1 DN 800, 16 PN, 32.008 Inch ID X 40.355 Inch OD X 0.063 Inch Thick, 24 Bolt Holes
| Bolt Circle Diameter (Inch) | 37.402 |
|---|---|
| Bolt Circle Diameter (mm) | 950.01 |
| Bolt Hole Diameter (Inch) | 1.536 |
| Bolt Hole Diameter (mm) | 39.01 |
| Bolt Hole Quantity | 24 |
| Brand | GYLON® |
| Color | Off-White |
| Compliances | FDA Compliant, REACH Compliant, RoHS Compliant, USP VI 87 Compliant, USP VI 88 Compliant, ADI/TSE Free |
| Compliances/Standards | ADI/TSE Free, FDA Compliant, REACH Compliant, RoHS Compliant, USP VI 87 Compliant, USP VI 88 Compliant |
| Composition | PTFE with Barium Sulfate |
| Diameter Nominal Pipe Size DN | 800 |
| Gasket Type | Full Face |
| Inside Diameter (Inch) | 32.008 |
| Inside Diameter (mm) | 813.00 |
| Min Temperature (C) | -268 |
| Min Temperature (F) | -450 |
| Outside Diameter (inch) | 40.355 |
| Outside Diameter (mm) | 1025.02 |
| Pressure Max (bar) | 55 |
| Pressure Max (psi) | 1200 |
| Pressure PN | 16 |
| Primary Dimensional Unit of Measure | Imperial |
| Primary Nominal Thickness | 1/16 |
| Rubber Chemical Name | Polytetrafluoroethylene |
| Rubber Material | PTFE |
| Sort Priority | 570 |
| Style/Model | Style 3510 |
| Temperature Range (C) | -268°C - 260°C |
| Temperature Range (F) | -450°F - 500°F |
| Thickness (inch) | 0.063 |
| Thickness (mm) | 1.60 |
Frequently Asked Questions
How do I get pricing for 37709EN-F0800404?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 37709EN-F0800404?
37709EN-F0800404 is a Garlock part. KKM Solutions sources Garlock components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 37709EN-F0800404?
Key specifications include Bolt Circle Diameter (Inch): 37.402; Bolt Circle Diameter (mm): 950.01; Bolt Hole Diameter (Inch): 1.536; Bolt Hole Diameter (mm): 39.01. The full specification table on this page lists every published attribute for this part.
How quickly can 37709EN-F0800404 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
