Garlock GYLON® Style 3505 Pipe Flange Gaskets
GYLON® Style 3505 Ring Gasket, PTFE with Aluminosilicate Microspheres EN 1514-1 DN 150, 10 PN, 6.654 Inch ID X 8.583 Inch OD X 0.063 Inch Thick Certified to NSF/ANSI/CAN 61-G & 372
| Brand | GYLON® |
|---|---|
| Color | Blue |
| Compliances | FDA Compliant, NSF® 61 Certified, REACH Compliant, RoHS Compliant, USP VI 87 Compliant, USP VI 88 Compliant, USP VI 661 Compliant, ADI/TSE Free, Oxygen Service |
| Compliances/Standards | ADI/TSE Free, FDA Compliant, NSF® 61 Certified, Oxygen Service, REACH Compliant, RoHS Compliant, USP VI 661 Compliant, USP VI 87 Compliant, USP VI 88 Compliant |
| Composition | PTFE with Aluminosilicate Microspheres |
| Diameter Nominal Pipe Size DN | 150 |
| Gasket Type | Ring |
| Inside Diameter (Inch) | 6.654 |
| Inside Diameter (mm) | 169.01 |
| Min Temperature (C) | -268 |
| Min Temperature (F) | -450 |
| Outside Diameter (inch) | 8.583 |
| Outside Diameter (mm) | 218.01 |
| Pressure Max (bar) | 55 |
| Pressure Max (psi) | 800 |
| Pressure PN | 10 |
| Primary Dimensional Unit of Measure | Imperial |
| Primary Nominal Thickness | 1/16 |
| Rubber Chemical Name | Polytetrafluoroethylene |
| Rubber Material | PTFE |
| Shipping Weight | 0.0834 lbs |
| Sort Priority | 550 |
| Style/Model | Style 3505 |
| Temperature Range (C) | -268°C - 260°C |
| Temperature Range (F) | -450°F - 500°F |
| Thickness (inch) | 0.063 |
| Thickness (mm) | 1.60 |
Frequently Asked Questions
How do I get pricing for 37132EN-R0150304?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 37132EN-R0150304?
37132EN-R0150304 is a Garlock part. KKM Solutions sources Garlock components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 37132EN-R0150304?
Key specifications include Brand: GYLON®; Color: Blue; Compliances: FDA Compliant, NSF® 61 Certified, REACH Compliant, RoHS Compliant, USP VI 87 Compliant, USP VI 88 Compliant, USP VI 661 Compliant, ADI/TSE Free, Oxygen Service; Compliances/Standards: ADI/TSE Free, FDA Compliant, NSF® 61 Certified, Oxygen Service, REACH Compliant, RoHS Compliant, USP VI 661 Compliant, USP VI 87 Compliant, USP VI 88 Compliant. The full specification table on this page lists every published attribute for this part.
How quickly can 37132EN-R0150304 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
