Danfoss Pressure transmitter, DST P92S, 0 bar - 250 bar, 0 psi - 3625 psi
Danfoss 078G1010 - DST P92S - Electrical connection: Deutsch; Type: DST P92S; Gross weight: 0.06 Kilogram.
The 078G1010 from Danfoss is listed under DST P92S in our catalog. The manufacturer's published data for this part number specifies Electrical connection: Deutsch and Type: DST P92S.
Key manufacturer data on file for this item includes Gross weight: 0.06 Kilogram; Net weight: 0.052 Kilogram; Volume: 0.109 Liter; EAN: 5702424048259; Product group: Sensors; Product Name Description: Pressure transmitter; China RoHS compliance: Out of scope; Contains batteries: No; EU RoHS compliance: Yes; Packing format: Multi pack; Quantity per packing format: 45 pc; REACH Candidate List substances: No. See the Specifications tab on this page for the full technical table.
| - common | Pin 2 |
|---|---|
| + supply | Pin 1 |
| Accuracy TEB [-25 - 80°C] ±FS | 1.5 % |
| Accuracy TEB [-40 - 80°C] ±FS | 2.5 % |
| Accuracy TEB [0 - 80°C] ±FS | 1 % |
| Approval | C UL US UL RecognizedCE |
| Burst pressure [bar] | 2500 bar |
| Burst pressure [psig] | 36250 psig |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Contains batteries | No |
| EAN | 5702424048259 |
| Electrical conn. comments | PBT |
| Electrical conn. Male/Female | Male |
| Electrical connection | Deutsch |
| Electrical connection size | 4 pin |
| Electrical connection standard | DT04 |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Gross weight | 0.06 Kilogram |
| Legacy part number | 11238559 |
| Medium temperature range [°C] [Max] | 125 °C |
| Medium temperature range [°C] [Min] | -40 °C |
| Medium temperature range [°F] [Max] | 185 °F |
| Medium temperature range [°F] [Min] | -104 °F |
| Net weight | 0.052 Kilogram |
| Output signal | Current |
| Output signal [mA] [Max] | 20 mA |
| Output signal [mA] [Min] | 4 mA |
| Overload pressure max. [bar] | 500 bar |
| Overload pressure max. [psig] | 7250 psig |
| Packing format | Multi pack |
| Pressure connection HEX [mm] | 22 mm |
| Pressure connection size | 7/16-20 |
| Pressure connection standard | SAE 4 |
| Pressure connection type | UNF |
| Pressure Male/Female | Male |
| Pressure range [bar] [Max] | 250 bar |
| Pressure range [bar] [Min] | 0 bar |
| Pressure range [psi] [Max] | 3625 psi |
| Pressure range [psi] [Min] | 0 psi |
| Pressure unit reference | Gauge (relative) |
| Product group | Sensors |
| Product Name Description | Pressure transmitter |
| Pulse-snubber | Yes |
| Quantity per packing format | 45 pc |
| REACH Candidate List substances | No |
| Response time max. [ms] | 1 ms |
| Specification key | DST P92S-0250-BAR-R-11-10-99 |
| Start up time [ms] | 40 ms |
| Supply voltage [V] DC [max] | 32 V |
| Supply voltage [V] DC [min] | 9 V |
| Type | DST P92S |
| UL evaluated | Yes |
| Volume | 0.109 Liter |
