Danfoss Pressure transmitter, DST P110, 0 bar - 50 bar, 0 psi - 725 psi
Danfoss 075G1020 - DST P110 - Housing material: 304L; Electrical connection: Round Packard Metri-Pack; Type: DST P110.
Danfoss 075G1020 is a DST P110 catalog item from Danfoss. The manufacturer's published data for this part number specifies Housing material: 304L and Electrical connection: Round Packard Metri-Pack.
Published specifications for this part include Type: DST P110; Gross weight: 0.07 Kilogram; Net weight: 0.062 Kilogram; Volume: 0.083 Liter; EAN: 5702428543385; Product group: Sensors; Product Name Description: Pressure transmitter; China RoHS compliance: Out of scope; Contains batteries: No; EU RoHS compliance: Yes; Packing format: Multi pack; Quantity per packing format: 64 pc. See the Specifications tab on this page for the full technical table.
| - common | Pin A |
|---|---|
| + output | Pin C |
| + supply | Pin B |
| Ambient temperature range [°C] [max] | 125 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Approval | C UL US UL RecognizedCE |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Compensated temp. range [°C] [Max] | 125 °C |
| Compensated temp. range [°C] [Min] | -40 °C |
| Contains batteries | No |
| EAN | 5702428543385 |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical connection | Round Packard Metri-Pack |
| Electrical connection size | 3 pin |
| Electrical connection standard | 150.2 SERIES |
| Electrical Connector Colour | Black |
| Enclosure rating IP | IP69K |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Fault signal level | 2 |
| Gross weight | 0.07 Kilogram |
| High Clipping Level | 99 |
| Housing material | 304L |
| Identical product | 075G4009 |
| In scope of WEEE | Yes |
| International Article Number | 5702428543385 |
| Low Clipping Level | 4 |
| Medium temperature range [°C] [Max] | 135 °C |
| Medium temperature range [°C] [Min] | -40 °C |
| Net weight | 0.062 Kilogram |
| Output signal | Ratio metric |
| Overload pressure max. [bar] | 200 bar |
| Overload pressure max. [psi] | 2900 psi |
| Packing format | Multi pack |
| Pressure connection HEX [mm] | 27 mm |
| Pressure connection size | 7/16-20 |
| Pressure connection standard | SAE J513 45° flare |
| Pressure connection type | UNF |
| Pressure Male/Female | Female |
| Pressure range [bar] [Max] | 50 bar |
| Pressure range [bar] [Min] | 0 bar |
| Pressure range [psi] [Max] | 725 psi |
| Pressure range [psi] [Min] | 0 psi |
| Pressure unit reference | Sealed gauge |
| Product group | Sensors |
| Product Name Description | Pressure transmitter |
| Pulse-snubber | No |
| Quantity per packing format | 64 pc |
| Ratiometric of Vsupply [%] [Max] | 90 % |
| Ratiometric of Vsupply [%] [Min] | 10 % |
| REACH Candidate List substances | No |
| Response time max. [ms] | 2 ms |
| Specification key | DST P110-2736-C2BF08-0 |
| Supply voltage [V] DC | 5 V |
| TEB inside CTR ±FS [%] | 3 % |
| Type | DST P110 |
| UL evaluated | Yes |
| Volume | 0.083 Liter |
| Wetted part material | 304L 316L |
