Bosch Rexroth SUPER LINEAR BUSHING KBB-25-D
Bosch Rexroth R067212540 - Linear Motion & Guides - Series: Super B (no self-alignment feature); Type: Linear bushing; Version: Normal.
This listing covers the Bosch Rexroth R067212540, a part number in the Linear Motion & Guides category. The manufacturer's published data for this part number specifies Series: Super B (no self-alignment feature) and Type: Linear bushing.
Speeds of up to 5 m/s possible. Service life is limited by heightened wear to plastic parts. Tests have shown total travel from 50 • 105 m to 100 • 105 m without failure.
The specification set recorded for this part number covers Version: Normal; Weight (Kg): 0.14; Seal: 1 integrated wiper seal; Dimension [d] [mm]: 40; Maximum acceleration rate amax [m/s²]: 150.0; Maximum permissible linear speed vmax [m/s]: 3.0; Dimension D1 [mm]: 38.5; Outer diameter D [mm]: 40.0; Lubrication: Not lubricated; Permissible ambient temperature (min. ... max.): -10 °C ... +80 °C; Shaft diameter d [mm]: 25.0; Format of linear bushings: – Closed. The complete technical table is shown in the Specifications tab on this page.
| Breakaway force [N] | 4.5 |
|---|---|
| Dimension [d] [mm] | 40 |
| Dimension C h13 [mm] | 58 |
| Dimension C1 H13 [mm] | 43.7 |
| Dimension C2 [mm] | 1.85 |
| Dimension D1 [mm] | 38.5 |
| Footnote breakaway force | One wiper seal: Multiply value with factor 0.5 |
| Footnote friction force FR | 1. One wiper seal: Multiply value with factor 0.5 2. Frictional drags generated by linear bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. |
| Footnote maximum dynamic load capacity Cmax | The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26. |
| Footnote minimum dynamic load capacity Cmin | The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26. |
| Format of linear bushings | – Closed |
| Friction coefficient μ | 0.001 ... 0.0025 |
| Length of linear bushing [mm] | 58.0 |
| Lubrication | Not lubricated |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum dynamic load capacity Cmax [N] | 4820.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Note: friction coefficient μ | Friction coefficients of unsealed linear bushings when lubricated with oil. The friction coefficient is lowest under heavy load, but can still be above the specified value even under a low load. |
| Note: maximum permissible speed vmax | Speeds of up to 5 m/s possible. Service life is limited by heightened wear to plastic parts. Tests have shown total travel from 50 • 10<sup>5</sup> m to 100 • 10<sup>5</sup> m without failure. |
| Outer diameter D [mm] | 40.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Seal | 1 integrated wiper seal |
| Series | Super B (no self-alignment feature) |
| Shaft diameter d [mm] | 25.0 |
| Type | Linear bushing |
| Version | Normal |
| Weight (Kg) | 0.14 |
Frequently Asked Questions
How do I get pricing for R067212540?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the R067212540?
R067212540 is a Bosch Rexroth part. KKM Solutions sources Bosch Rexroth components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of R067212540?
Key specifications include Breakaway force [N]: 4.5; Dimension [d] [mm]: 40; Dimension C h13 [mm]: 58; Dimension C1 H13 [mm]: 43.7. The full specification table on this page lists every published attribute for this part.
How quickly can R067212540 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
