Balluff BTL5-E50-M0437-J-M01-TA
BTL118C (BTL5-E50-M0437-J-M01-TA) - Magnetostrictive linear position sensors for explosive areas - List price USA: 3,675.64 USD - Style: Rod Series Ex, Mounting part: Flange Ø 18h6 plus holes, Housing material: Aluminum, Anodized, Magnets, number max.: 1, Connection: Clamping terminal, 7-pin, Analog output: Analog, current 4…20 mA, Measuring range: 437 mm, Non-linearity max.: ±100 µm, Repeat accuracy: ± 5 µm, Operating voltage Ub: 10...30 VDC, Ambient temperature: -40...80 °C, IP rating: IP68, Approval/Conformity: CE, UKCA, CSA, IECEx, WEEE, Ex category: ATEX: 1G (EPL Ga), ATEX: 1D (EPL Da), IECEx: EPL Ga, IECEx: EPL Da, NEC 500: Class I, Division 1, NEC 505: Class I, Zone 1 - BALLUFF USA
| Ambient temperature | -40...80 °C |
|---|---|
| Analog output | Analog, current 4…20 mA |
| Approval/Conformity | CE, UKCA, CSA, IECEx, WEEE |
| Connection | Clamping terminal, 7-pin |
| Ex category | ATEX: 1G (EPL Ga), ATEX: 1D (EPL Da), IECEx: EPL Ga, IECEx: EPL Da, NEC 500: Class I, Division 1, NEC 505: Class I, Zone 1 |
| Housing material | Aluminum, Anodized |
| IP Rating | IP68 |
| Magnets, number max. | 1 |
| Measuring range | 437 mm |
| Mounting part | Flange Ø 18h6 plus holes |
| Non-linearity max. | ±100 µm |
| Operating voltage Ub | 10...30 VDC |
| Repeat accuracy | ± 5 µm |
| Style | Rod Series Ex |
Frequently Asked Questions
How do I get pricing for BTL118C?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BTL118C?
BTL118C is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of BTL118C?
Key specifications include Ambient temperature: -40...80 °C; Analog output: Analog, current 4…20 mA; Approval/Conformity: CE, UKCA, CSA, IECEx, WEEE; Connection: Clamping terminal, 7-pin. The full specification table on this page lists every published attribute for this part.
How quickly can BTL118C ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
