Balluff BES M05EC-PSC08B-ES05-T
BES05R9 (BES M05EC-PSC08B-ES05-T) - Temperature-rated inductive sensors - Dimension: Ø 5 x 25 mm, Style Housing: M5x0.5, Installation: for flush mounting, Range: 0.8 mm, Switching output: PNP Normally open (NO), Switching frequency: 5 kHz, Housing material: Stainless steel, Material sensing surface: PA 6.6, Connection: Cable, 5 m, Silicone, Operating voltage Ub: 10...30 VDC, Ambient temperature: -25...120 °C, IP rating: IP67, Approval/Conformity: CE, EAC, WEEE - BALLUFF USA
| Ambient temperature | -25...120 °C |
|---|---|
| Connection | Cable, 5 m, Silicone |
| Dimension | Ø 5 x 25 mm |
| Housing material | Stainless steel |
| Installation | for flush mounting |
| IP Rating | IP67 |
| Material sensing surface | PA 6.6 |
| Operating voltage Ub | 10...30 VDC |
| Range | 0.8 mm |
| Style Housing | M5x0.5 |
| Switching frequency | 5 kHz |
| Switching output | PNP Normally open (NO) |
Frequently Asked Questions
How do I get pricing for BES05R9?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BES05R9?
BES05R9 is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of BES05R9?
Key specifications include Ambient temperature: -25...120 °C; Connection: Cable, 5 m, Silicone; Dimension: Ø 5 x 25 mm; Housing material: Stainless steel. The full specification table on this page lists every published attribute for this part.
How quickly can BES05R9 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
