Allen-Bradley Sound Module 70 mm Stack Lights 855T-G24SA1
Allen-Bradley 855T-G24SA1 - industrial components - Outer Diameter: 69.5 mm mm; Function: Other; Operating Temperature: -25 °C.
The 855T-G24SA1 from Allen-Bradley is listed under industrial components in our catalog. The manufacturer's published data for this part number specifies Outer Diameter: 69.5 mm mm and Function: Other.
Key manufacturer data on file for this item includes Operating Temperature: -25 °C; Storage Temperature: -40 °C; Lifecycle Status: Discontinued; Build America, Buy America: No; Repair Options Available: No; Sub Brand: Sound Module; Degree of protection (IP): IP54; Degree of protection (NEMA): 12; Colour: Other; Operating voltage: 24V AC/DC (±10%); Current consumption: 65mA @ 24V AC/DC; Materials: Rubber seals and gaskets: Nitrile rubber. See the Specifications tab on this page for the full technical table.
| Build America, Buy America | No |
|---|---|
| Colour | Other |
| Current consumption | 65mA @ 24V AC/DC |
| Decibel rating | Maximum volume ranges from 64...103 dBa (volume adjustable), Based on tone that is selected for all settings except signal horn, which has a maximum of 80 dBa |
| Degree of protection (IP) | IP54 |
| Degree of protection (NEMA) | 12 |
| Function | Other |
| Lamp life rating | Sound modules: 20000 h |
| Leakage current impact | All sound modules can absorb up to 3 mA of leakage current from solid-state outputs without module activation |
| Lifecycle Status | Discontinued |
| Materials | Rubber seals and gaskets: Nitrile rubber |
| Module type | Single-tone sound module with 13 different tones (this module uses one circuit in a stack. it can be used with maximum of any four light modules and must be placed on top of stack) |
| Operating Temperature | -25 °C |
| Operating voltage | 24V AC/DC (±10%) |
| Operating voltage at DC | 24 V |
| Outer Diameter | 69.5 mm mm |
| Recommended terminal torque | 0.8 Nm |
| Recommended wire size | 0.5 mm² |
| Repair Options Available | No |
| Storage Temperature | -40 °C |
| Sub Brand | Sound Module |
| Tone adjustable | true |
| Voltage type | AC/DC |
Frequently Asked Questions
How do I get pricing for 855T-G24SA1?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 855T-G24SA1?
855T-G24SA1 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 855T-G24SA1?
Key specifications include Build America, Buy America: No; Colour: Other; Current consumption: 65mA @ 24V AC/DC; Decibel rating: Maximum volume ranges from 64...103 dBa (volume adjustable), Based on tone that is selected for all settings except signal horn, which has a maximum of 80 dBa. The full specification table on this page lists every published attribute for this part.
How quickly can 855T-G24SA1 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
