Allen-Bradley Panel Mount Strobe Panel Mount Strobe 855PS-B20ME622
Allen-Bradley 855PS-B20ME622 - industrial components - Height: 72 mm mm; Weight: 60 g; Operating Temperature: -25 °F.
The 855PS-B20ME622 from Allen-Bradley is listed under industrial components in our catalog. The manufacturer's published data for this part number specifies Height: 72 mm mm and Weight: 60 g.
Published specifications for this part include Operating Temperature: -25 °F; Storage Temperature: -25 °F; Nominal current: 12mA @ 230/240V AC, 50/60 Hz; Size: 45 mm diam; Lifecycle Status: Discontinued; Build America, Buy America: No; Repair Options Available: No; Degree of protection (IP): IP65; Degree of protection (NEMA): 4X; Terminals: Plug-in terminal block, up to 2.5 mm² (14 AWG), IP2X; Mounting: Central mounting for bore holes 22 mm or 30.5 mm with hole adapter kit; Mounting method: Other. See the Specifications tab on this page for the full technical table.
| Build America, Buy America | No |
|---|---|
| Degree of protection (IP) | IP65 |
| Degree of protection (NEMA) | 4X |
| Flash energy | 1.5 j |
| Flashing frequency, min | 1.4 Hz |
| Height | 72 mm mm |
| Housing base material | Polycarbonate |
| Housing Color | Black |
| Housing lenses | Polycarbonate |
| Lamp type | Xenon |
| Lens color | Blue |
| Lifecycle Status | Discontinued |
| List of degrees of protection (IP) | IP65, IP2X |
| List of degrees of protection (NEMA) | 4, 4X, 13 |
| Mounting | Central mounting for bore holes 22 mm or 30.5 mm with hole adapter kit |
| Mounting hole | 22.5 mm round mounting hole |
| Mounting method | Other |
| Mounting nut torque | 1.7 nm |
| Nominal current | 12mA @ 230/240V AC, 50/60 Hz |
| Nominal Voltage | 240 V |
| Operating Temperature | -25 °F |
| Repair Options Available | No |
| Size | 45 mm diam |
| Storage Temperature | -25 °F |
| Suitable for ceiling mounting | false |
| Suitable for wall mounting | false |
| Supply voltage | 230/240V (±10%) AC 50/60 Hz |
| Terminals | Plug-in terminal block, up to 2.5 mm² (14 AWG), IP2X |
| Turn-ON leakage current | ≥3 mA |
| Type of current | AC |
| Weight | 60 g |
| With contact | false |
Frequently Asked Questions
How do I get pricing for 855PS-B20ME622?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 855PS-B20ME622?
855PS-B20ME622 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 855PS-B20ME622?
Key specifications include Build America, Buy America: No; Degree of protection (IP): IP65; Degree of protection (NEMA): 4X; Flash energy: 1.5 j. The full specification table on this page lists every published attribute for this part.
How quickly can 855PS-B20ME622 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
