Allen-Bradley Assembled Station 800G PB 800G-3FAAFBAE4A1
Allen-Bradley 800G-3FAAFBAE4A1 - industrial components - Material: Enclosure/housing material: Thermoplastic, Seal material: EPDM; Operating Temperature: -55 °C; Storage Temperature: -55 °C.
The Allen-Bradley 800G-3FAAFBAE4A1 is part of the industrial components range in our industrial catalog. The manufacturer's published data for this part number specifies Material: Enclosure/housing material: Thermoplastic, Seal material: EPDM and Operating Temperature: -55 °C.
Key manufacturer data on file for this item includes Storage Temperature: -55 °C; Degree of protection: Contact block with screw termination: IP20, with operators and enclosure IP66; Lifecycle Status: Discontinued; Build America, Buy America: No; Repair Options Available: No; Degree of protection (IP): IP66; Degree of protection (NEMA): 4X; Suitable for emergency stop: true; Mechanical life operations: Push-pull mushroom push button (emergency stop) operator: 6000 cycles; Enclosure size: 3 unit enclosure; Material housing: Plastic; Contact rating: A600/P600 per UL 508 with screw/cable termination. The complete technical table is shown in the Specifications tab on this page.
| B10D value for base mount contact block with screw termination | 1200000 cycles (The B10D value [cycles] states the number of switching cycles up to which 10% of the elements failed dangerously. The determination was done via a statistical evaluation of field data) |
|---|---|
| B10D value for latch mount contact block with screw/cable termination | 1200000 cycles (The B10D value [cycles] states the number of switching cycles up to which 10% of the elements failed dangerously. The determination was done via a statistical evaluation of field data) |
| B10D value for non-illuminated flush push button | 5800000 cycles (The B10D value [cycles] states the number of switching cycles up to which 10% of the elements failed dangerously. The determination was done via a statistical evaluation of field data) |
| B10D value for push-pull mushroom push button | 140000 cycles (The B10D value [cycles] states the number of switching cycles up to which 10% of the elements failed dangerously. The determination was done via a statistical evaluation of field data) |
| Break current at rated voltage, max | 1.2A @ 600V AC per UL contact rating with screw/cable termination |
| Build America, Buy America | No |
| Cable glands, custom | Metal M20 for cable, outer sheath: Ø 15.5...21.1 mm (Ø 0.61...0.83 in), Metal M25 for cable, outer sheath: Ø 20.3...27.4 mm (Ø 0.80...1.08 in), 19.05 mm (3/4 in) NPT conduit hub |
| Cable glands, standard | 12.7 mm (1/2 in) NPT conduit hub |
| Conduit/cable entry | Bottom, 0.5 in NPT hub |
| Contact block/lamp module position 1 | 1 NO, 1 NC base mount |
| Contact block/lamp module position 2 | 1 NO, 1 NC base mount |
| Contact block/lamp module position 3 | 1 NO, 1 NC base mount |
| Contact material | Contact block with screw/cable termination: AgSnO2 |
| Contact rating | A600/P600 per UL 508 with screw/cable termination |
| Degree of protection | Contact block with screw termination: IP20, with operators and enclosure IP66 |
| Degree of protection (IP) | IP66 |
| Degree of protection (NEMA) | 4X |
| Enclosure size | 3 unit enclosure |
| Impact resistance | Push-pull mushroom push button (emergency stop) operator: 7 Nm |
| Ingress protection rating | Front of panel operators IP66: -20...70 °C (-4...158 °F), IP54: -55...-20 °C (-67...-4 °F), Type 4X: -20...70 °C (-4...158 °F) |
| Lifecycle Status | Discontinued |
| List of degrees of protection (IP) | IP54, IP66 |
| Make current at rated voltage, max | 12A @ 600V AC per UL contact rating with screw/cable termination |
| Material | Enclosure/housing material: Thermoplastic, Seal material: EPDM |
| Material housing | Plastic |
| Mechanical life operations | Push-pull mushroom push button (emergency stop) operator: 6000 cycles |
| Mounting | Contact block with screw termination, Base mount: Secures to rail integral to enclosure base, Panel mount: Secures to operator with integral latch |
| Number of mushroom-shaped push-buttons | 1 |
| Number of operator positions | 3 |
| Number of push buttons | 1 |
| Operating force | Push-pull mushroom push button (emergency stop) operator (excludes contact block): 44.5 N push/89 N pull |
| Operating force, max | Contact block, full travel with screw/cable termination: 28.9 N |
| Operating Temperature | -55 °C |
| Operator position 1 | Non-illuminated flush push button |
| Operator position 2 | Non-illuminated flush push button |
| Operator position 3 | Push-pull mushroom push button (Emergency-stop, only available in Red with English/French legend) |
| PE conductor terminals | 4 x 2.5 mm² stranded maximum |
| Pushbutton & pilot light color | Red |
| Pushbutton & pilot light text | STOP (Red background/White text) |
| Rated insulation voltage | Contact block with screw termination: 690V |
| Rated insulation voltage, max | 690V AC |
| Rated operational current | Contact block with screw/cable termination: 16A @ 250V AC, per utilization category AC-12 |
| Rated voltage | Contact block with screw/cable termination: 250V AC (per ATEX certificates) |
| Rated voltage per UL contact rating, max | Contact block with screw/cable termination: 600V AC/DC |
| Repair Options Available | No |
| Shock resistance | Contact block with screw/cable termination: DIN IEC 68 part 2-27, 30 G, 18 ms |
| Short circuit protection | Contact block with screw/cable termination: 10 A slow blow, Type DT, gl |
| Storage Temperature | -55 °C |
| Stranded wire/cable size, max | 2.5 mm² |
| Suitable for emergency stop | true |
| Thermal continuous current | Contact block with screw/cable termination: 16A @ 40°C |
| Thermal continuous test current | 5A @ 600V DC per UL contact rating with screw/cable termination |
| Utilization category | Contact block with screw/cable termination: AC-12, AC-15, DC-13 |
| Wire/cable size | Screw termination: 2.5 mm² (12 AWG) stranded maximum |
