Allen-Bradley DeviceNet Power Device 1485T-P1M4-MN5KF
Allen-Bradley 1485T-P1M4-MN5KF - industrial components - Operating Temperature: -25 °C; Lifecycle Status: Active; Build America, Buy America: No.
This listing covers the Allen-Bradley 1485T-P1M4-MN5KF, a part number in the industrial components category. The manufacturer's published data for this part number specifies Operating Temperature: -25 °C and Lifecycle Status: Active.
Published specifications for this part include Build America, Buy America: No; Repair Options Available: No; Depth, approx: Male, mini: 34.5 mm; Width, approx: Male, mini: 73.8 mm; Enclosure type rating: NEMA 6P, 12 and 13, IP67, 1200 psi (8270 kPa) washdown; Rated voltage: 50 V; Product Type Feature: Standard material: Epoxy-coated Zinc coupling nuts; Assembly rating: Mini to mini: 50V @ 8A, mini to micro: 50V @ 4A; Contact type: Pin; Degree of protection (IP), mounted: IP67; Material of contact surface: Gold; Rated current In: 8 A. The complete technical table is shown in the Specifications tab on this page.
| Assembly rating | Mini to mini: 50V @ 8A, mini to micro: 50V @ 4A |
|---|---|
| Build America, Buy America | No |
| Bulletin Number | Devices used to provide input of power into devicenet networks |
| Contact type | Pin |
| Degree of protection (IP), mounted | IP67 |
| Depth, approx | Male, mini: 34.5 mm |
| Diameter connector | 25.4 mm |
| Drop connector type | Mini male 4-pin |
| Enclosure type rating | NEMA 6P, 12 and 13, IP67, 1200 psi (8270 kPa) washdown |
| Keyway orientation | Keyway on drop connector toward female trunk connector |
| Lifecycle Status | Active |
| Material of contact surface | Gold |
| Number of drop ports | T-port (1 drop connector) with mini trunk connectors |
| Operating Temperature | -25 °C |
| Product Type Feature | Standard material: Epoxy-coated Zinc coupling nuts |
| Rated current In | 8 A |
| Rated voltage | 50 V |
| Repair Options Available | No |
| Trunk connection | Two mini style connectors, one male and one female |
| Width, approx | Male, mini: 73.8 mm |
| With status indication | false |
Frequently Asked Questions
How do I get pricing for 1485T-P1M4-MN5KF?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 1485T-P1M4-MN5KF?
1485T-P1M4-MN5KF is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 1485T-P1M4-MN5KF?
Key specifications include Assembly rating: Mini to mini: 50V @ 8A, mini to micro: 50V @ 4A; Build America, Buy America: No; Bulletin Number: Devices used to provide input of power into devicenet networks; Contact type: Pin. The full specification table on this page lists every published attribute for this part.
How quickly can 1485T-P1M4-MN5KF ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
