Allen-Bradley IEC Enclosed Reversing Starter 105-C09AA-OLR-4RG
Allen-Bradley 105-C09AA-OLR-4RG - industrial components - Width: 7.36 mm mm; Height: 12.91 mm mm; Lifecycle Status: Active.
Allen-Bradley 105-C09AA-OLR-4RG is a industrial components catalog item from Allen-Bradley. The manufacturer's published data for this part number specifies Width: 7.36 mm mm and Height: 12.91 mm mm.
The specification set recorded for this part number covers Lifecycle Status: Active; Build America, Buy America: No; Repair Options Available: No; Control Type: Common Control; Enclosure Type: IP42/NEMA 1 Mtl; Degree of protection (IP): IP42; Degree of protection (NEMA): 1; Depth: 5.52 mm; Factory installed models: Pilot light (red - FORWARD, green - REVERSE); Number of indicator lights: 2; Overload relay: Provision for overload relay; Rated control supply voltage at AC 50 Hz: 220 V. See the Specifications tab on this page for the full technical table.
| Build America, Buy America | No |
|---|---|
| Control Type | Common Control |
| Degree of protection (IP) | IP42 |
| Degree of protection (NEMA) | 1 |
| Depth | 5.52 mm |
| Enclosure Type | IP42/NEMA 1 Mtl |
| Enclosure type rating | Type 1 - IP42 (Metal) |
| Factory installed models | Pilot light (red - FORWARD, green - REVERSE) |
| Height | 12.91 mm mm |
| Hp rating, max | 2Hp @ 230V (AC3, AC4), 3-phase, 60 Hz |
| KW power | 3 kW @ 230V (AC3, AC4), 3-phase, 50 Hz |
| Lifecycle Status | Active |
| Number of indicator lights | 2 |
| Overload relay | Provision for overload relay |
| Rated control supply voltage at AC 50 Hz | 220 V |
| Rated control supply voltage at AC 60 Hz | 230 V |
| Rated operation current Ie | 9 A |
| Repair Options Available | No |
| Temperature compensated overload protection | true |
| Type of electrical connection for auxiliary- and control current circuit | Screw connection |
| Type of electrical connection of main circuit | Screw connection |
| Type of motor starter | Reversing starter |
| Voltage type for actuating | AC |
| Width | 7.36 mm mm |
| With fuse | false |
| With short-circuit release | false |
| With transformer | false |
