Allen-Bradley IEC 80 A Contactor 100-E80KD00
Allen-Bradley 100-E80KD00 - IEC Magnetic Contactors - Function: Non-reversing contactor; Ambient temperature: Storage: -40...+70 (-40...+158); Lifecycle Status: Active.
The Allen-Bradley 100-E80KD00 is part of the IEC Magnetic Contactors range in our industrial catalog. The manufacturer's published data for this part number specifies Function: Non-reversing contactor and Ambient temperature: Storage: -40...+70 (-40...+158).
Key manufacturer data on file for this item includes Lifecycle Status: Active; Build America, Buy America: No; Repair Options Available: No; Rated control supply voltage at AC 50 Hz: 100 V; Rated control supply voltage at AC 60 Hz: 100 V; Type of electrical connection of main circuit: Screw connection; Voltage type for actuating: AC/DC; Number of auxiliary contacts as normally open contact: 0; Coil voltage: 100 to 250V AC/DC; Number of auxiliary contacts as normally closed contact: 0; Rated control supply voltage at DC: 100 V; Rated isolation voltage (Ui): 600V per UL, CSA. The complete technical table is shown in the Specifications tab on this page.
| Altitude, max | 3000 m of installation site |
|---|---|
| Ambient temperature | Storage: -40...+70 (-40...+158) |
| Build America, Buy America | No |
| Climatic withstand | Category B according to IEC 60947-1, annex Q |
| Coil voltage | 100 to 250V AC/DC |
| DIN fuses (gG) current rating | Type 2 (per IEC 60947-4-1): 80A @ 690V, 60 kA available fault current |
| Electromagnetic compatibility | IEC 60947-1 - Environment A and B (100-E09...E38 only.) |
| Features | Panel mounting or mounting on 35 mm DIN rail, AC/DC electronic coil, Made of environmentally friendly materials |
| FLA | 105A @ 600V, 3-phase per UL/CSA HVAC applications |
| Function | Non-reversing contactor |
| General purpose current (enclosed) | 80A @ 600V per UL/CSA |
| Lifecycle Status | Active |
| LRA | 630 A @ 440-480V AC, 3-phase per UL/CSA HVAC applications |
| MCCB current rating | Type 2 (per IEC 60947-4-1): 880A @ 400V, 70 kA available fault current |
| Number of auxiliary contacts as normally closed contact | 0.000000 |
| Number of auxiliary contacts as normally open contact | 0.000000 |
| Operating limits, dropout | (≤0.60) x Us @ DC control |
| Operating limits, pick-up | (0.85...1.1) x Us @ 50/60 Hz |
| Operating time, closing delay | 42 ms |
| Operating time, opening delay | 17 ms |
| Optional accessories | Side-or front-mount auxiliary contacts, Mechanical interlocks, IP20 terminal shields, Connecting bars |
| Optional overload relays | Electronic |
| Protection class | Contactor main contact: IP2X (100-E40...E96 meet IP2X when used with 100-ESC...terminal shrouds.) |
| Rated control supply voltage at AC 50 Hz | 100 V |
| Rated control supply voltage at AC 60 Hz | 100 V |
| Rated control supply voltage at DC | 100 V |
| Rated impulse voltage withstand (Uimp) | 8 kV |
| Rated isolation voltage (Ui) | 600V per UL, CSA |
| Rated operational current (Ie) | 85A @ 690V, AC-1 active power load (50/60 Hz), ambient temperature 70 °C (158 °F) |
| Rated operational current and power | 56A @ 115V AC, 500000 electrical ops, 1-phase per UL/CSA elevator duty |
| Rated operational current and power (enclosed) | 89A @ 250V DC, with 3-poles in series per UL/CSA |
| Rated operational power (Pe) | 90 kW @ 415V, AC-1 active power load (50/60 Hz), ambient temperature 40 °C (104 °F) |
| Rated voltage (Ue) | 24V @ 48V, 110V @ 220V, 440V DC |
| Rating for switching AC motors | 3-poles: 75Hp @ 575V, AC-2, AC-3 (60 Hz) |
| Repair Options Available | No |
| Shock resistance | IEC 60068-2-27 |
| Standard coil, hold-in | 4VA/2 W @ 100...250V AC/DC |
| Standard coil, pick-up | 40VA/40 W @ 100...250V AC/DC |
| Switching of DC loads | 3-poles in series: 125A @ 220V (Shunt-wound motors starting, reverse current breaking, reversing, stepping DC-3 at 60 °C) |
| Switching of lighting loads | Tungsten lA: 105A @ 600V, 3-phase (break all lines) per UL/CSA |
| Switching of power transformers | Apparent power: 99 kVA @ 600V @ 60Hz (n = 20) |
| Type of electrical connection of main circuit | Screw connection |
| UL class J and CSA HRCI-J fuses rating | Type 1 Combination (per UL 60947 and CSA 22.2 No. 14): 200A @ 600V, 100 kA available fault current |
| UL class RK5 fuses rating | Type 1 Combination (per UL 60947 and CSA 22.2 No. 14): 200A @ 600V, 10 kA available fault current |
| UL inverse-time circuit breaker | Type 1 Combination (per UL 60947 and CSA 22.2 No. 14): 250A @ 600V, 50 kA available fault current |
| Vibration resistance | IEC 60068-2-6 |
| Voltage type for actuating | AC/DC |
